White SPI COG Graphic LCD Display 192x64 UC1609 FPC Connection
- Buy 10 for US$3.59 each and save 3%
- Buy 30 for US$3.48 each and save 6%
- Buy 50 for US$3.38 each and save 8%
- Buy 100 for US$3.28 each and save 11%
- Buy 500 or more Quote Request
Description
ERC19264FS-4 is white background with 192x64 monochrome Black pixels,UC1609C controller that is extremely common and well documented,it s 3/4-wire,I2C serial spi interface,fstn-lcd positive,wide operating temperature range and wide view angle,rohs compliant,compact size. It's soldering type FPC,no connector is needed.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
ERC19264-4 Datasheet | English | Mar-22-2022 |
880K
|
|
Controller IC UC1609C Datasheet | English | Mar-01-2012 | 733K |
Tutorial- 8051 Microcontroller
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
English | Mar-25-2022 | 401K |
Gross Weight (kg) | 0.0280 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2022. |
Part Number | ERC19264FS-4 |
Display Format | 192x64 Dots |
Interface | I2C, 3-wire SPI, 4-wire SPI |
IC or Equivalent | UC1609C |
Appearance | Black on White |
Diagonal Size | 2.0” |
Connection | Soldering FPC |
Outline Dimension | 53.90(W)x37.10(H)x4.45(T)mm |
Visual Area | 51.00x17.20mm |
Active Area | 47.98(W)x15.98(H) |
Dot (Pixel) Size | 0.23x0.23mm |
Dot (Pixel) Pitch | 0.25x0.25mm |
IC Package | COB |
Display Type | FSTN-LCD Grey |
Touch Panel Optional | No |
Sunlight Readable | No |
Viewing Direction | 12:00 |
Viewing Angle Range | Left:50.0 , Right:50.0 , Up:40.0 , Down:40.0 degree |
Backlight Color | White Color |
Backlight Current (Typ) | 70mA |
Power Supply(Typ) | 3.3V |
Supply Current for LCM(Max) | 350uA |
Operating Temperature | -20℃~70℃ |
Storage Temperature | -30℃~80℃ |
