12.1 inch 800x600 TFT LCD Display w/Optional Touch Panel,LVDS Interface
- Buy 10 for US$110.70 each and save 3%
- Buy 30 for US$107.65 each and save 5%
- Buy 50 for US$104.71 each and save 8%
- Buy 100 for US$101.72 each and save 11%
- Buy 500 or more Quote Request












Description
ER-TFT121-1 is 800x600 Pixels 12.1" color tft lcd display panel with HX8245+HX8677 driver,optional resistive touch panel,superior display quality,super wide view angle, It's LVDS interface.
It can be used in any embedded systems,consumer electronics,car,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.
What's included in the package ?
Number | Standard Accessory Name | Quantity |
---|---|---|
1 | 12.1 inch 800x600 pixels TFT LCD Display | 1 |
2 | LVDS Cable | 1 |
3 | Backlight Cable | 1 |
Datasheet for TFT LCD Display
Format | Documents Name | Version | Language | Update Date | Size |
---|---|---|---|---|---|
![]() |
12.1 inch 800x600 Dots TFT LCD Display Datasheet | 1.0 | English |
Aug-15-2019 |
690K |
Datasheet for Touch Panel
Format | Documents Name | Version | Language | Update Date | Size |
---|---|---|---|---|---|
![]() |
12.1 inch 4-Wire Resistive Touch Panel Datasheet | 1.0 | English | Jun-10-2019 | 470K |
Gross Weight (kg) | 0.7000 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
Part Number | ER-TFT121-1 |
Display Format | 800x600 Pixels |
Interface | LVDS |
IC or Equivalent | N/A |
Appearance | RGB |
Diagonal Size | 12.1“ |
Connection | LVDS Wire-Connection |
Outline Dimension | 279.00(W)x209.00(H)X9.0(T)mm |
Visual Area | 249.05x188.30mm |
Active Area | 246.00(W)x184.50(H)mm |
Dot (Pixel) Pitch | 0.3075(W)x0.3075(H)mm |
IC Package | COG |
Display Type | TFT-LCD Color |
Touch Panel Optional | Yes |
Sunlight Readable | No |
Contrast Ratio(Typ) | 400:1 |
Colors | 65K/262K/16.7M |
Viewing Angle Range | Left:80.0 , Right:80.0 , Up:65.0 , Down:75.0 degree |
Brightness(Typ) | 400cd/m2 |
Backlight Color | White Color |
Backlight Current (Typ) | 475mA |
Power Supply(Typ) | 3.3V |
Operating Temperature | -20℃~70℃ |
Storage Temperature | -30℃~80℃ |
