Color 12.1 inch Raspberry PI TFT Display w/HDMI+Video Board,800x600
- Buy 10 for US$122.83 each and save 3%
- Buy 30 for US$119.51 each and save 5%
- Buy 50 for US$116.19 each and save 8%
- Buy 100 for US$112.87 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-TFT121-1-5795 is a 12.1-inch TFT display with a resolution of 800x600 pixels. It comes with an HDMI+Video board, which allows for easy connection to the Raspberry Pi's HDMI output. It's optional 4-wire resistive touch panel with USB driver board and cable, optional louder speaker and extention cable for power.
ER-TFT121-1-5795 also features a high brightness level, which makes it easy to view in bright environments. Additionally, it has a fast response time, which minimizes motion blur and makes it suitable for use in fast-paced applications such as gaming.
Overall, ER-TFT121-1-5795 is a high-quality display that is well-suited for a wide range of applications, including embedded systems, digital signage, and gaming. Its large size and high resolution make it ideal for displaying detailed images and text, while its compatibility with the Raspberry Pi and easy connectivity make it a convenient and versatile choice for DIY electronics projects.
What's included in the package ?
| Number | Standard Accessory Name | Qty |
|---|---|---|
| 1 | 12.1 inch TFT LCD 800x600 Pixels Display | 1 |
| 2 | LVDS Cable | 1 |
| 3 | Backlight Cable | 1 |
| 4 | HDMI Driver Board | 1 |
| 5 | Keyboard Cable with Terminal | 1 |
Datasheet for TFT LCD Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT121-1-5795 Datasheet | English |
Dec-15-2022 |
1.2M |
Datasheet for Resistive Touch Panel
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Jun-10-2019
|
470K | |
|
English |
Jun-19-2013
|
190K | |
 |
English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 1.0000 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2022. |
| Part Number | ER-TFT121-1-5795 |
| Display Format | 800x600 Pixels |
| Interface | HDMI |
| IC or Equivalent | RTD2513 |
| Appearance | RGB |
| Diagonal Size | 12.1“ |
| Connection | LVDS Wire-Connection |
| Outline Dimension | 279.00(W)x209.00(H)x9.0(T)mm |
| Visual Area | 249.05x188.30mm |
| Active Area | 246.00(W)x184.50(H)mm |
| Dot (Pixel) Pitch | 0.3075(W)x0.3075(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 800:1 |
| Colors | 65K/262K/16.7M |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:65.0 , Down:75.0 degree |
| Brightness(Typ) | 400cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 220mA |
| Power Supply(Typ) | 12V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
