320x132 White 3.83" SPI OLED Display Double SSD1320 16-Level Grayscale
- Buy 10 for US$37.30 each and save 3%
- Buy 30 for US$36.23 each and save 6%
- Buy 50 for US$35.16 each and save 8%
- Buy 100 for US$34.10 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-OLED0383-1W is the graphic OLED display panel made of 320x132 individual white OLED pixels,16-level grayscale,diagonal is 3.83 inch.The controller ic SSD1320, communicates via 4-wire SPI serial interface,thanks to controller's built-in voltage generation,only a single 3.3V power supply is needed. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the connector type,we offer optional zif connector(fpc connector).
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for OLED Display,IC Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-OLED0383-1_Datasheet | English | May-20-2020 |
1.8M
|
 |
ER-OLED0383-1_3D Model | English | Aug-25-2023 | 311K |
|
Controller IC SSD1320 Datasheet | English |
May-16-2017
|
1.45M |
|
16 Pins 0.5mm Pitch ZIF Connector Drawing | English |
Jul-26-2012
|
264K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Jun-01-2020 | 196K |
| Gross Weight (kg) | 0.0320 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2020. |
| Part Number | ER-OLED0383-1W |
| Display Format | 320x132 Dots |
| Interface | 4-Wire Serial SPI |
| IC or Equivalent | SSD1320 |
| Appearance | White on Black |
| Diagonal Size | 3.83" |
| Connection | FFC-Connector |
| Outline Dimension | 105.52(W)x41.67(H)x2.0(T)mm |
| Visual Area | 90.90x38.07mm |
| Active Area | 89.90(W)x30.07(H)mm |
| Dot (Pixel) Size | 0.26x0.26mm |
| Dot (Pixel) Pitch | 0.28x0.28mm |
| IC Package | COG |
| Display Type | OLED |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Viewing Angle Range | Free |
| Brightness(Typ) | 100cd/m2 |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -40℃~70℃ |
| Storage Temperature | -40℃~85℃ |
