SPI 1.45 inch 160x128 Full Color RGB OLED Display Panel Free View
- Buy 10 for US$18.20 each and save 3%
- Buy 30 for US$17.70 each and save 5%
- Buy 50 for US$17.21 each and save 8%
- Buy 100 for US$16.72 each and save 11%
- Buy 500 or more Quote Request
-
This Item:
SPI 1.45 inch 160x128 Full Color RGB OLED Display Panel Free View
US$18.69
-
8051 Microcontroller Development Board for OLED Display ER-OLED1.45-1C
US$22.26
-
Total price
Description
ER-OLED1.45-1C is the full color graphic OLED display panel made of 160xRGBx128 OLED pixels,diagonal is only 1.45 inch.The controller ic SEPS525, communicates via 6-bit RGB,8080 8-bit/9-bit Parallel or 4-wire serial SPI, interface. Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the connector type,we offer optional zif connector(fpc connector).
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for OLED Display,Controller,Connector
Format | Documents Name | Version | Language | Update Date | Size |
---|---|---|---|---|---|
1.45 inch 160x128 Pixels OLED Display Panel Datasheet | 1.0 | English |
Dec-02-2019
|
687K
|
|
Controller IC SEPS525 Datasheet | 1.0 | English | Apr-14-2016 | 1.3M | |
35Pins 0.5mm Pitch Top Contact FPC Connector Datasheet | 1.0 | English | Jul-26-2012 | 258K |
Tutorial- 8051 Microcontroller
Format | Documents Name | Version | Language | Update Date | Size |
---|---|---|---|---|---|
1.0 | English |
Dec-10-2019
|
423K | ||
N/A | N/A |
N/A
|
N/A |
Gross Weight (kg) | 0.0190 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
Part Number | ER-OLED1.45-1C |
Display Format | 160x128 Dots |
Interface | 4-wire SPI, 6800 9-bit Parallel , 8080 8-bit Parallel , 6-bit RGB |
IC or Equivalent | SEPS525 |
Appearance | RGB |
Diagonal Size | 1.45“ |
Connection | Plug-in FPC |
Outline Dimension | 35.80(W)x30.80(H)x1.6(T)mm |
Visual Area | 30.78x25.02mm |
Active Area | 28.78(W)x23.02(H)mm |
Dot (Pixel) Size | 0.04x0.164mm |
Dot (Pixel) Pitch | 0.06x0.18mm |
IC Package | COG |
Display Type | OLED |
Touch Panel Optional | No |
Sunlight Readable | No |
Contrast Ratio(Typ) | 10000:1 |
Colors | 262K |
Viewing Angle Range | Free |
Brightness(Typ) | 100cd/m2 |
Power Supply(Typ) | 2.8V |
Operating Temperature | -40℃~70℃ |
Storage Temperature | -40℃~85℃ |
