Square 0.85 inch 128x128 IPS TFT LCD Display 4-wire SPI GC9107
- Buy 10 for US$2.27 each and save 3%
- Buy 30 for US$2.21 each and save 6%
- Buy 50 for US$2.15 each and save 8%
- Buy 100 for US$2.09 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-TFT0.85-2 is square 0.85-inch IPS TFT display, featuring a sharp resolution of 128x128 pixels. With an impressive contrast ratio of 1000:1, it excels in rendering deep blacks and vibrant colors, ensuring a visually striking experience.The IPS technology allows full viewing angle.its brightness level of 350cd/m2 ensures clear and vibrant visuals even in brightly lit environments.
ER-TFT0.85-2 is equipped with the GC9107 controller. It features a 4-wire SPI interface that ensures stable and efficient data transmission. That is suitable for a wide range of applications, including industrial control systems, home automation and portable electronics. It featurs a connctor type FPC with optional FPC connector.
For users of the 8051 microcontroller, we have carefully prepared a comprehensive interfacing document, demonstration code, and an 8051 development board specifically tailored for this display.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 0.85 inch 128x128 Pixels TFT LCD Display | 1 |
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT0.85-2 Datasheet | English | Feb-24-2024 | 650K |
|
Controller GC9107_Datasheet | English | Jan-01-2021 | 2.5M |
|
12 Pins 0.50mm Pitch ZIF Connector Drawing | English | Jul-01-2023 | 267K |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Mar-08-2024 | 280K |
| Gross Weight (kg) | 0.0180 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
| Part Number | ER-TFT0.85-2 |
| Display Format | 128x128 Pixels (Dots) |
| Interface | 4-wire SPI |
| IC or Equivalent | GC9107 |
| Appearance | RGB |
| Diagonal Size | 0.85“ |
| Connection | Plug-in FPC |
| Outline Dimension | 17.58(W)x20.82(H)x1.4(T)mm |
| Visual Area | 15.72x15.70mm |
| Active Area | 15.21(W)x15.21(H) |
| Dot (Pixel) Pitch | 0.18x0.18mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 1000:1 |
| Colors | 4K/65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 350cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 20mA |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
