White 0.96 inch 64x128 OLED Display Screen SH1107 SPI I2C Interface
- Buy 10 for US$2.07 each and save 2%
- Buy 30 for US$2.00 each and save 6%
- Buy 50 for US$1.95 each and save 8%
- Buy 100 for US$1.89 each and save 11%
- Buy 500 or more Quote Request
Description
ER-OLED0.96-7W is the graphic OLED display panel made of 64x128 individual white OLED pixels,diagonal is only 0.96 inch.The controller ic SH1107, communicates via 4-wire SPI serial interface,Because the display makes its own light, no backlight is required. This reduces the power required to run the OLED and is why the display has such high contrast,extremely wide viewing angle and extremely operating temperature.The fpc is the soldering type,no need connector.Just solder the FPC on your PCB directly.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held device.
Datasheet
Format | Documents Name | Version | Language | Update Date | Size |
---|---|---|---|---|---|
0.96 inch 64x128 Pixels OLED Display Panel Datasheet | 1.0 | English | Jun-01-2020 |
1.1M
|
|
Controller IC SH1107 Datasheet | 2.1 | English | Dec-01-2014 | 459K |
Tutorial- 8051 Microcontroller
Format | Documents Name | Version | Language | Update Date | Size |
---|---|---|---|---|---|
1.0 | English | Nov-24-2020 | 222K |
Gross Weight (kg) | 0.0180 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2020. |
Part Number | ER-OLED0.96-7W |
Display Format | 64x128 Dots |
Interface | I2C, 4-Wire Serial SPI |
IC or Equivalent | SH1107 |
Appearance | White on Black |
Diagonal Size | 0.96“ |
Connection | FPC-Soldering |
Outline Dimension | 28.00(W)x14.00(H)x1.2(T)mm |
Visual Area | 22.74x11.86mm |
Active Area | 21.74(W)x10.86(H)mm |
Dot (Pixel) Size | 0.15x0.15mm |
Dot (Pixel) Pitch | 0.17x0.17mm |
IC Package | COG |
Display Type | OLED |
Touch Panel Optional | No |
Sunlight Readable | No |
Viewing Angle Range | Free |
Brightness(Typ) | 100cd/m2 |
Power Supply(Typ) | 2.8V |
Operating Temperature | -40℃~70℃ |
Storage Temperature | -40℃~85℃ |
