1.8 inch 128x160 TFT LCD Display 4-wire SPI ST7735S Soldering Type FPC
- Buy 10 for US$1.82 each and save 3%
- Buy 30 for US$1.77 each and save 5%
- Buy 50 for US$1.72 each and save 8%
- Buy 100 for US$1.67 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ER-TFT018-4 is 1.8-inch TFT display, featuring a resolution of 128x160 pixels. With an contrast ratio of 300:1 and brightness level of 250cd/m2 ensures clear and vibrant visuals in most environments.
ER-TFT018-4 is equipped with the ST7735S controller. It features a 4-wire SPI interface that ensures stable and efficient data transmission. That is suitable for a wide range of applications, including industrial control systems, home automation and portable electronics. It featurs a soldering type FPC that eliminates the need for an FPC connector, simplifying the installation process.
We recommend ER-TFTM018-5 that is essentially the ER-TFT018-4 display panel equipped with a breakout board, facilitating seamless connections to devices such as Arduino or Raspberry Pi with interfacing documents,libraries and examples.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 1.8 inch 128x160 Pixels TFT LCD Display | 1 |
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT018-4_Datasheet | English | Feb-24-2024 | 2.0M |
|
Controller ST7735S_Datasheet | English | Nov-01-2011 | 3.0M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
8051 Interfacing and Demo Code | English | Mar-24-2024 | 263K |
| Gross Weight (kg) | 0.0210 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2024. |
| Part Number | ER-TFT018-4 |
| Display Format | 128x160 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | ST7735S |
| Appearance | RGB |
| Diagonal Size | 1.8“ |
| Connection | Soldering FPC |
| Outline Dimension | 34.74(W)x46.70(H)x2.3(T)mm |
| Visual Area | 29.03x36.04mm |
| Active Area | 28.03(W)x35.04(H)mm |
| Dot (Pixel) Pitch | 0.218x0.219mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 300:1 |
| Colors | 4K/65K/262K |
| Viewing Angle Range | Left:60.0 , Right:60.0 , Up:50.0 , Down:60.0 degree |
| Brightness(Typ) | 250cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 40mA |
| Power Supply(Typ) | 2.8V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
