16x2 LCD 3.3v Character COG Display Module,,Black on White
- Buy 10 for US$3.68 each and save 2%
- Buy 30 for US$3.58 each and save 5%
- Buy 50 for US$3.49 each and save 7%
- Buy 100 for US$3.39 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Description
ERC1602FS-4 is 16 characters wide,2 row cog(chip on glass,no board) character lcd module,compact size,metal pin connection,ST7032i controller,i2c+4-wire serial interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,fstn-lcd positive,black text on the white color,high contrast,wide operating temperature range,wide view angle,rohs compliant,built in character set supports English/Japanese text,see the ST7032i datasheet for the full character set.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for Character LCD Module,Controller IC
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
16x2 Character COG LCD Module Datasheet | 1.0 | English | May-19-2013 |
397K
|
|
Controller IC ST7032 Datasheet | 1.2 | English | Oct-17-2005 | 1.2M |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
1.0 | English |
May-20-2013
|
8K | |
|
1.0 | English |
May-23-2013
|
6K | |
|
1.0 | English |
May-27-2013
|
157K | |
 |
8051 Microcontroller Development Board&Kit for ERC1602-4
|
N/A | N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.0350 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2015. |
| Part Number | ERC1602FS-4 |
| Display Format | 16x2 Character |
| Interface | I2C, 4-Wire Serial SPI |
| IC or Equivalent | ST7032i |
| Appearance | Black on White |
| Diagonal Size | 1.9“ |
| Connection | Pin Header |
| Outline Dimension | 68.6(W)x26.0(H)x6.0(T)mm |
| Visual Area | 64.60x16.00mm |
| Active Area | 56.25(W)x11.50(H)mm |
| Dot (Pixel) Size | 0.55x0.65mm |
| Dot (Pixel) Pitch | 0.60x0.70mm |
| IC Package | COG |
| Display Type | FSTN-LCD Grey |
| Touch Panel Optional | No |
| Sunlight Readable | Yes |
| Viewing Direction | 12:00 |
| Viewing Angle Range | Left:50.0 , Right:50.0 , Up:40.0 , Down:40.0 degree |
| Brightness(Typ) | 80cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 15mA |
| Power Supply(Typ) | 3.3V |
| Supply Current for LCM(Max) | 300uA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
