3.2 inch IPS TFT LCD Display with Arduino Shield for Mega/Due/Uno
- Buy 10 for US$17.09 each and save 3%
- Buy 30 for US$16.62 each and save 5%
- Buy 50 for US$16.16 each and save 8%
- Buy 100 for US$15.70 each and save 11%
- Buy 500 or more Quote Request












-
This Item:
3.2 inch IPS TFT LCD Display with Arduino Shield for Mega/Due/Uno
US$17.55
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
UNO R3 ATmega328P Development Board For Arduino Compatible+USB Cable
US$11.80
-
Total price
Description
This arduino shield provides a convenient and effective solution for incorporating the ER-TFT032IPS-3.2-41334 display module that is 3.2 inch ips tft lcd display with ST7789V controller and breakout board into Arduino projects, providing both touchscreen options and ease of use through our library and examples.
For people who want the same screen but not in a shield, check this
What's included in the package ?
Number | Standard Accessory Name | Quantity |
---|---|---|
1 | 3.2 inch TFT LCD Display with ST7789V2 Controller and Breakout Board | 1 |
2 | Arduino Shield | 1 |
*The default power supply is 5V and the default interface is 4-wire serial interface.
Compatible with following Arduino Boards
Board Name | MCU | I/O |
---|---|---|
Arduino MEGA2560 | ATMEGA2560 | 54 |
Arduino MEGA1280 | ATMEGA1280 | 54 |
Arduino Due | AT91SAM3X8EA | 54 |
Arduino Uno | ATMEGA328 | 14 |
Datasheet for Display Module
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
ER-TFT032IPS-3.2-4334_Datasheet | English |
Jul-07-2023 |
1.6M |
![]() |
Controller ST7789V2_Datasheet | English | Nov-01-2016 | 3.0M |
Datasheet and Schematic for Arduino Shield
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
ER-AS-ILI9341 Datasheet | English | Feb-24-2016 | 828K |
![]() |
ER-AS-ILI9341 Arduino Schematic Diagram | English | Oct-16-2018 | 192K |
Tutorial - Arduino
Format | Documents Name | Language | Update Date | Size |
---|---|---|---|---|
![]() |
ER-TFT032IPS-3.2-4334_Arduino_Tutorial | English | Jul-22-2023 | 2.0M |
Gross Weight (kg) | 0.1060 |
---|---|
Manufacturer | EastRising |
Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
Part Number | ER-TFT032IPS-3.2-4334-4123 |
Display Format | 240x320 Pixels |
Interface | 3-wire SPI, 4-wire SPI, 8080 8-bit Parallel , 8080 16-bit Parallel |
IC or Equivalent | ST7789 |
Appearance | RGB |
Diagonal Size | 3.2” |
Connection | Pin Header, Plug-in FFC |
Outline Dimension | 64.90(W)x89.40(H)mm |
Visual Area | 50.20x66.40mm |
Active Area | 48.60(W)x64.80(H)mm |
Dot (Pixel) Pitch | 0.202x0.202 |
IC Package | COG |
Display Type | TFT-LCD Color |
Touch Panel Optional | Yes |
Sunlight Readable | No |
Contrast Ratio(Typ) | 500:1 |
Colors | 65K/262K |
Viewing Direction | IPS |
Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
Brightness(Typ) | 280cd/m2 |
Backlight Color | White Color |
Power Supply(Typ) | 5V |
Supply Current for LCM(Max) | 130mA (Vdd=5V) |
Operating Temperature | -20℃~70℃ |
Storage Temperature | -30℃~80℃ |
