6.95" 600x1024 TFT Module SPI/I2C Opt. Capacitive Touch Arduino Shield
- Buy 10 for US$31.62 each and save 3%
- Buy 30 for US$30.76 each and save 5%
- Buy 50 for US$29.91 each and save 8%
- Buy 100 for US$29.06 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
6.95" 600x1024 TFT Module SPI/I2C Opt. Capacitive Touch Arduino Shield
US$32.47
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$18.69
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$18.69
-
UNO R3 ATmega328P Development Board For Arduino Compatible+USB Cable
US$9.34
-
New WINBOND IC Chip FLASH 128M BIT W25Q128JV SOP8 Package
US$1.87
-
Total price
Description
The ER-TFT6.95-1-6304 from EastRising is a 6.95-inch IPS TFT LCD display module with a resolution of 600 (RGB) x 1024 pixels, offering a balanced blend of size and clarity. It utilizes an IPS panel for wide 80°/80°/80°/80° viewing angles and displays 262K colors with a typical brightness of 300 cd/m². The module is driven by a versatile LT7683 controller board, providing simple host integration via 3-wire/4-wire SPI and I2C interfaces. It operates from a flexible 3.3V or 5V power supply. This module is an excellent choice for applications requiring a reliable, medium-sized display with excellent viewing characteristics.
An Arduino shield is available for this TFT display module, providing seamless integration with popular Arduino mainboards such as the Uno and Mega. This accessory simplifies the connection process, allowing for quick setup and evaluation.
An 8051 evaluation board is available for this TFT module. It is designed to simplify hardware interfacing and accelerate software development, enabling quick and reliable integration with 8051-based microcontroller systems.
Of course, we wouldn't just leave you with a datasheet and a "good luck!" We prepared the interfacing documents,libraries and examples for arduino due,mega 2560,uno,For 8051 microcontroller user,we also prepared the interfacing document and demo code.
Datasheet
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT6.95-1-6304_Datasheet | English | Dec-12-2025 |
1.1M
|
|
Controller LT7683 Datasheet | English | Jul-10-2020 | 4.8M |
|
Controller SSD2828 Bridge Chip Datasheet | English | May-27-2013 | 1.1M |
Datasheet for Flash Memory
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
128M-BIT Flash W25Q128FV Datasheet | English | Oct-01-2012 | 1.0M |
Datasheet for ZIF Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Jul-26-2012
|
269K |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
English |
Dec-16-2025
|
2.9M |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English | Dec-16-2025 |
1.2M |
Tutorial - ESP32
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ESP32_Example | English | Dec-16-2025 |
2.9M |
| Gross Weight (kg) | 0.1150 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2025. |
| Part Number | ER-TFT6.95-1-6304 |
| Display Format | 600x1024 Pixels |
| Interface | I2C, 3-wire SPI, 4-wire SPI |
| IC or Equivalent | LT7683 |
| Appearance | RGB |
| Diagonal Size | 6.95" |
| Connection | Plug-in FFC |
| Outline Dimension | 94.90(W)x162.45(H)mm |
| Visual Area | 90.28x153.37mm |
| Active Area | 89.28(W)x152.37(H)mm |
| Dot (Pixel) Pitch | 0.148x0.148mm |
| IC Package | SMT |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 800:1 |
| Colors | 262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 300cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 3.3V |
| Supply Current for LCM(Max) | 590mA ( VDD=3.3V) / 450mA ( VDD=5.0V) |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
