8" TFT LCD Display EJ080NA-05A 800X600 8 inch TFT LCD Screen 50 Pins
Availability: In stock
US$33.64
- Buy 10 for US$32.75 each and save 3%
- Buy 30 for US$31.85 each and save 5%
- Buy 50 for US$30.98 each and save 8%
- Buy 100 for US$30.10 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Description
ER-TFT080-2 is 800x600 pixels 8" color tft lcd display with HX8264 driver IC,optional 4-wire resistive touch panel and optional capacitive touch panel with connector,superior display quality,super wide view angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO, ARM and Raspberry PI.
It can be used in any embedded systems,car,mp4,gps,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It supports rgb interface. FPC with zif connector is easily to assemble or remove.
The LED backlight driver IC we suggest to use for this display is PT4110.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 8 inch 800x600 pixels TFT LCD Display | 1 |
Datasheet for TFT LCD Display,Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT080-2_Datasheet | English |
Dec-14-2022 |
927K |
 |
ER-TFT080-2_3D Model | English | Sep-15-2023 | 312K |
|
Driver IC (HX8264-D05) Datasheet (Active) Datasheet | English | Feb-01-2011 | 1.9M |
|
50 Pins 0.50mm Pitch ZIF Connector Drawing | English | Jul-26-2012 | 273K |
Datasheet for Touch Panel,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8 inch 4-wire Resistive Touch Panel Drawing | English | Jun-21-2014 | 266K |
|
|
4 Pins 1.0mm Pitch ZIF Connector Drawing for Touch Panel | English | Jul-26-2012 | 268K |
|
|
8 inch Capacitive Touch Panel with Controller | English | Nov-22-2018 | 288K |
|
|
Capacitive Touch Controller GT911 Datasheet | English | Mar-11-2015 | 1.6M |
|
|
6 Pins 0.5mm Pitch ZIF Connector Drawing for Touch Panel | English | Jun-10-2014 | 272K |
| Gross Weight (kg) | 0.3680 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2019. |
| Part Number | ER-TFT080-2 |
| Display Format | 800x600 Pixels |
| Interface | RGB |
| IC or Equivalent | HX8264 |
| Appearance | RGB |
| Diagonal Size | 8.0“ |
| Connection | FPC-Connector |
| Outline Dimension | 183.00(W)x141.00(H)x5.6(T)mm |
| Visual Area | 164.80x124.30mm |
| Active Area | 162.00(w)x121.50(H)mm |
| Dot (Pixel) Pitch | 0.2025(W)x0.2531(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Angle Range | Left:70.0 , Right:70.0 , Up:50.0 , Down:70.0 degree |
| Brightness(Typ) | 420cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 150mA |
| Power Supply(Typ) | 3.3V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
Write Your Own Review
Please send us quote request for part Number
ER-TFT080-2
If you order quantity per lot is more than 500pcs or send email to [email protected]
