Low-Cost Blue 4004 40x4 Charcter LCD Display Module
- Buy 10 for US$10.04 each and save 3%
- Buy 30 for US$9.75 each and save 6%
- Buy 50 for US$9.47 each and save 8%
- Buy 100 for US$9.18 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
Low-Cost Blue 4004 40x4 Charcter LCD Display Module
US$10.33
-
8051 Microcontroller Development Board for Character LCD ERM4004-1
US$44.75
-
Total price
Description
ERMC4004SBS-1 is 40 characters wide,4 rows character lcd module,AIP31066 controller (Industry-standard HD44780 compatible controller),6800 4/8-bit parallel interface,single led backlight with white color included can be dimmed easily with a resistor or PWM,stn- blue lcd negative,white text on the blue color,wide operating temperature range,rohs compliant,built in character set supports English/Japanese text, see the SPLC780C datasheet for the full character set.Optional 3.3v or 5v power supply and optional pin header connection.
It's easily controlled by MCU such as 8051,PIC,AVR,ARDUINO,ARM and Raspberry Pi.It can be used in any embedded systems,industrial device,security,medical and hand-held equipment.
Of course, we wouldn't just leave you with a datasheet and a "good luck!".For 8051 microcontroller user,we prepared the detailed tutorial such as interfacing, demo code and Development Kit at the bottom of this page.
Datasheet for Character LCD Module,Controller IC
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ERMC4004-1_Series_Datasheet | English | Jul-07-2023 |
1.4M
|
|
Controller IC AIP31066_Datasheet | English | Jul-09-2002 | 813K |
Tutorial- 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
English |
Jul-20-2023
|
342K | |
 |
N/A |
N/A
|
N/A |
| Gross Weight (kg) | 0.1430 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ERMC4004SBS-1 |
| Display Format | 40x4 Character |
| Interface | 6800 4-bit Parallel , 6800 8-bit Parallel |
| IC or Equivalent | AIP31066 , HD44780, KS0066 , SPLC780 , ST7066 |
| Appearance | White on Blue |
| Diagonal Size | 2.34“ |
| Connection | Pin Header |
| Outline Dimension | 190.00(W)x54.0(H)x13.2(T)mm |
| Visual Area | 146.50x29.80mm |
| Active Area | 140.22(W)x23.00(H)mm |
| Dot (Pixel) Size | 0.50x0.56mm |
| Dot (Pixel) Pitch | 0.56x0.62mm |
| IC Package | COB |
| Display Type | STN-LCD Blue |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Viewing Direction | 6:00 |
| Viewing Angle Range | Left:50.0 , Right:50.0 , Up:40.0 , Down:40.0 degree |
| Brightness(Typ) | No |
| Backlight Color | White Color |
| Backlight Current (Typ) | 120mA |
| Power Supply(Typ) | 3.3V, 5V |
| Supply Current for LCM(Max) | 3500uA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
