1.65 inch 142x428 IPS TFT LCD Display Module for Arduino,Raspberry PI
US$4.11
- Buy 10 for US$3.99 each and save 3%
- Buy 30 for US$3.90 each and save 5%
- Buy 50 for US$3.79 each and save 8%
- Buy 100 for US$3.68 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
1.65 inch 142x428 IPS TFT LCD Display Module for Arduino,Raspberry PI
US$4.11
-
Raspberry Pi Zero W V1.3 with WIFI and Bluetooth
US$27.31
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$23.61
-
Total price
Description
ER-TFTM1.65-2 is 142x428 pixels 1.65 inch ips tft lcd display with NV3007 controller and breakout board,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.It's 4-wire serial spi interface.
For this product, we have also meticulously prepared interfacing documents, libraries, and examples specifically tailored for the Arduino Due, Mega 2560, Uno, Nano, as well as the Raspberry Pi and Raspberry Pi Zero. This ensures seamless integration and easy control for users working with these popular platforms.
What's included in the package ?
| Number | Standard Accessory Name | Quantity |
|---|---|---|
| 1 | 1.65" 142x428 Pixels TFT LCD Display with Breakout Board | 1 |
Datasheet for Display
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFTM1.65-2_Datasheet | English | Mar-26-2025 | 583K |
|
Controller NV3007_Datasheet | English | Jun-19-2024 | 2.8M |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Mar-29-2025 | 1.2M |
Tutorial- Raspberry Pi
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
Raspberry Pi Library and Example | English | Mar-29-2025 | 2.0M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | English | Mar-29-2025 | 310K |
Tutorial - ESP32
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ESP32_Example | English | Apr-22-2025 | 90K |
| Gross Weight (kg) | 0.0210 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2025. |
| Part Number | ER-TFTM1.65-2 |
| Display Format | 142x428 Pixels |
| Interface | 4-wire SPI |
| IC or Equivalent | NV3007 |
| Appearance | RGB |
| Diagonal Size | 1.65" |
| Connection | Pin Header |
| Outline Dimension | 28.30(W)x46.00(H)mm |
| Visual Area | 13.76x40.28mm |
| Active Area | 13.16(W)x39.68(H)mm |
| Dot (Pixel) Pitch | 0.09x0.09mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | No |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 700:1 |
| Colors | 65K/262K |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 350cd/m2 |
| Backlight Current (Typ) | N/A |
| Power Supply(Typ) | 3V |
| Supply Current for LCM(Max) | 60mA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
