3.5" IPS 320x240 TFT Display Module LQ035NC111,LQ035NC211 for Arduino
- Buy 10 for US$18.50 each and save 3%
- Buy 30 for US$18.00 each and save 5%
- Buy 50 for US$17.50 each and save 8%
- Buy 100 for US$17.00 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
3.5" IPS 320x240 TFT Display Module LQ035NC111,LQ035NC211 for Arduino
US$19.00
-
EANSDI 1GB TF Flash Memory Card Micro SD
US$4.83
-
New WINBOND IC Chip FLASH 128M BIT W25Q128JV SOP8 Package
US$1.87
-
DUE R3 Board SAM3X8E 32-bit ARM Cortex-M3 for Arduino w/USB Cable
US$60.49
-
ATMEGA16U2 Board For Arduino Mega 2560 R3 Board 2012 Kit w/USB Cable
US$20.66
-
UNO R3 ATmega328P Development Board For Arduino Compatible+USB Cable
US$11.80
-
Total price
Description
ER-TFT035-3-5609 is 320x240 pixels 3.5 inch color ips tft lcd module with LT7680 controller board ,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.
It supports 4-wire serial SPI interface.Built-in microSD card slot,optional capacitive touch panel with controller CST340,so you can detect finger presses anywhere on the screen and doesn't require pressing down on the screen with a stylus.
It's optional for flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested.
Also we design the arduino shield for this module,so the customers can easily connect this module with arduino Mega2560 or Uno board through shield.
Of course, we wouldn't just leave you with a datasheet and a "good luck!" We prepared the interfacing documents,libraries and examples for arduino due,mega 2560,uno,For 8051 microcontroller user,we also prepared the interfacing document and demo code.
Datasheet for TFT LCD Module,Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT035-4-5609 Datasheet | English |
Dec-07-2023 |
1.2M |
|
Controller LT7680 Datasheet | English | Jul-10-2020 | 4.2M |
|
20 Pins 1.00mm Pitch ZIF Connector Drawing | English | Jul-26-2012 | 268K |
Datasheet for Touch Panel,Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
3.5 inch Capacitive Touch Panel Outline Drawing | English |
Mar-17-2021 |
234K |
|
Capacitive Touch Panel Controller CST340 Datasheet | English |
Jul-24-2014 |
2.3M |
Datasheet for Flash Memory,MicroSD Card Slot
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
128M-BIT Flash W25Q128JV Datasheet | English | Mar-27-2018 | 1.07M |
|
|
MicoSD Card Slot Drawing | English | Mar-28-2012 |
307K |
Datasheet for Schematic And Arduino Shield
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
ER-AS-5517 Datasheet | English | Dec-14-2021 | 1.1M |
|
|
ER-AS-5517 Arduino Schematic Diagram | English | Apr-25-2021 |
243K |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Nov-20-2023 | 2.1M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | English | Nov-20-2023 | 613K |
| Gross Weight (kg) | 0.0750 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2023. |
| Part Number | ER-TFT035-4-5609 |
| Display Format | 320x240 Pixels |
| Interface | 4-Wire Serial SPI |
| IC or Equivalent | LT7680 |
| Appearance | RGB |
| Diagonal Size | 3.5” |
| Connection | Pin Header, FFC-Connector |
| Outline Dimension | 88.90(W)x63.90(H)mm |
| Visual Area | 72.90x55.30mm |
| Active Area | 70.08(W)x52.56(H)mm |
| Dot (Pixel) Pitch | 0.219x0.219mm |
| IC Package | SMT |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 1200:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 400cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 3.3V, 5V |
| Supply Current for LCM(Max) | 200mA (Vdd=3.3V) 150mA (Vdd=5V) |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
