8" inch Raspberry Pi Touch Screen TFT LCD Display w/HDMI Driver Board
Availability: In stock
US$42.47
- Buy 10 for US$41.40 each and save 3%
- Buy 30 for US$40.21 each and save 5%
- Buy 50 for US$39.16 each and save 8%
- Buy 100 for US$38.04 each and save 10%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
Shipping
We cooperate with DHL,FEDEX,TNT,EMS China Post and Singapore Post for shipment and choose the most appropriate one for the destination .A shipping cost estimate is displayed during online checkout based on the country you provide.
Payment
We primarily use paypal to process secure online payments. Through PayPal, we accept MasterCard, VISA, American Express,Discover cards.We also accept payment by wire transfer and west union.
Tax Information
ALL prices listed on buydisplay exclude taxes,import fees, and customs duties. Customers may be subject to these fees.
Warranty
All products are covered under our limited warranty, which provides all products are free of functional defects for a period of one year after receipt of order and all products are free of visual defects and missing parts for a period of 7 days after receipt of order.If a product was damaged during shipping or the order is incorrect, please notify us within 3 days after receipt of order.
Return Policy
Products under warranty can be returned for repair or replacement.Before returning a product, you must contact us for a Return Material Authorization (RMA).If you have a product out of warranty that you would like to repair, please also contact us.
Continulty Supply
We promise the long terms continuity supply.Some controller IC or glass cell may stop the production by supplier,we'll try our efforts to find the compatible ones as replacement.
Frequently Bought Together
-
This Item:
8" inch Raspberry Pi Touch Screen TFT LCD Display w/HDMI Driver Board
US$42.47
-
AC100-240V To DC 5V 2A Power Supply Adapter for TFT Driving Board
US$3.11
-
Total price
Attention
All the accessories listed below tier pricing need to pay.We won't deliver until you select. Power adaptor should be 5V/2000mA in output and center pin for positive voltage and the outer shield for negative voltage .The temperature for controller RTD2660 would increase during working.That's normal phenomenon,not quality problem.
When lose signal,the screen is blue or black that is available in the menu setting.There is no snowy screen or white noise in setting menu.
Description
ER-TFTV080A1-1 is 800x480 dots 8"color tft lcd module display with small HDMI signal driver board,optional 8 inch 4-wire resistive touch panel, touch panel usb port controller board,remote control,superior display quality,super wide view angle.It can be used in any embedded systems,car,industrial device,security and hand-held equipment which requires display in high quality and colorful video.It's also ideal for Raspberry PI by HDMI.
What's included in the package ?
| Number | Standard Accessory Name | Qty |
|---|---|---|
| 1 | 8 inch TFT LCD 800x480 Pixels Display | 1 |
| 2 | Small HDMI Driver Board | 1 |
| 3 | Keyboard Cable with Terminal | 1 |
| 4 | Power Cable with Terminal | 1 |
Datasheet for TFT LCD Display
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
 |
8 inch TFT LCD with Small HDMI Driver Board Datasheet | 1.0 | English | Nov-29-2017 |
646K
|
Datasheet for Capacitive Touch Panel and USB Controller Board
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
ER-TPC080-3-USB Outline Drawing | 1.0 | English |
Oct-10-2018
|
276K
|
Datasheet for Resistive Touch Panel,Connector
| Format | Documents Name | Version | Language | Update Date | Size |
|---|---|---|---|---|---|
|
1.0 | English |
Feb-02-2013
|
247K | |
|
1.0 | English |
Jun-19-2013
|
190K | |
 |
1.0 | English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 0.4380 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2017. |
| Part Number | ER-TFTV080A1-1 |
| Display Format | 800x480 Pixels |
| Interface | HDMI |
| IC or Equivalent | OTA7001A |
| Appearance | RGB |
| Diagonal Size | 8.0“ |
| Connection | FPC-Connector |
| Outline Dimension | 192.8(W)x116.9(H)mm |
| Visual Area | 180.10x103.40mm |
| Active Area | 176.64(W)x99.36(H)mm |
| Dot (Pixel) Size | 0.0736(W)x0.207(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 500:1 |
| Colors | 65K/262K/16.7M |
| Viewing Angle Range | Left:70.0 , Right:70.0 , Up:50.0 , Down:70.0 degree |
| Brightness(Typ) | 200cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 5V |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
Write Your Own Review
Please send us quote request for part Number
ER-TFTV080A1-1
If you order quantity per lot is more than 500pcs or send email to [email protected]
