Description
ER-TFTM035-3 is 320x240 pixels 3.5 inch color tft lcd module with LT7680 controller board ,superior display quality,super wide viewing angle and easily controlled by MCU such as 8051, PIC, AVR, ARDUINO,ARM and Raspberry PI.It can be used in any embedded systems,industrial device,security and hand-held equipment which requires display in high quality and colorful image.
It supports 4-wire serial SPI interface.Built-in microSD card slot,optional 4-wire resistive touch panel with controller XPT2046 and capacitive touch panel with controller CST340,so you can detect finger presses anywhere on the screen and doesn't require pressing down on the screen with a stylus.
It's optional for flash chip and microsd card. We offer two types connection,one is pin header and the another is ZIF connector with flat cable mounting on board by default and suggested.
Also we design the arduino shield for this module,so the customers can easily connect this module with arduino Mega2560 or Uno board through shield.
Of course, we wouldn't just leave you with a datasheet and a "good luck!" We prepared the interfacing documents,libraries and examples for arduino due,mega 2560,uno,For 8051 microcontroller user,we also prepared the interfacing document and demo code.
Datasheet for TFT LCD Module,Controller,Connector
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFTM035-3 Datasheet | English |
Dec-02-2021 |
1.2M |
|
Controller LT7680 Datasheet | English | Jul-10-2020 | 4.2M |
|
20 Pins 1.00mm Pitch ZIF Connector Drawing | English | Jul-26-2012 | 268K |
Datasheet for Touch Panel,Controller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
3.5 inch 4-Wire Resistive Touch Panel w/Soldering Type FPC | English |
Jun-06-2016 |
242K |
|
|
Resistive Touch Panel Controller XPT2046 Datasheet | English | May-01-2007 | 579K |
|
3.5 inch Capacitive Touch Panel Outline Drawing | English |
Mar-17-2021 |
234K |
|
Capacitive Touch Panel Controller CST340 Datasheet | English |
Jul-24-2014 |
2.3M |
Datasheet for Flash Memory,MicroSD Card Slot
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
128M-BIT Flash W25Q128JV Datasheet | English | Mar-27-2018 | 1.07M |
|
|
MicoSD Card Slot Drawing | English | Mar-28-2012 |
307K |
Datasheet for Schematic And Arduino Shield
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
ER-AS-5517 Datasheet | English | Dec-14-2021 | 1.1M |
|
|
ER-AS-5517 Arduino Schematic Diagram | English | Apr-25-2021 |
243K |
Tutorial- Arduino
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
Arduino Library and Example | English | Dec-06-2021 | 2.1M |
Tutorial - 8051 Microcontroller
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
|
8051 Interfacing and Demo Code | English | Dec-06-2021 | 794K |
| Gross Weight (kg) | 0.0750 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2021. |
| Part Number | ER-TFTM035-3 |
| Display Format | 320x240 Pixels |
| Interface | 4-Wire Serial SPI |
| IC or Equivalent | LT7680 |
| Appearance | RGB |
| Diagonal Size | 3.5” |
| Connection | Pin Header, FFC-Connector |
| Outline Dimension | 88.90(W)x63.90(H)mm |
| Visual Area | 72.88x54.96mm |
| Active Area | 70.08(W)x52.56(H)mm |
| Dot (Pixel) Pitch | 0.219x0.219mm |
| IC Package | SMT |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 400:1 |
| Colors | 65K/262K |
| Viewing Direction | 12:00 |
| Viewing Angle Range | Left:60.0 , Right:60.0 , Up:50.0 , Down:55.0 degree |
| Brightness(Typ) | 400cd/m2 |
| Backlight Color | White Color |
| Power Supply(Typ) | 3.3V, 5V |
| Supply Current for LCM(Max) | 150mA (Vdd=3.3V) 200mA (Vdd=5V) |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
