Raspberry Pi 5 inch 1024x600 IPS TFT LCD Display w/HDMI Driver Board
- Buy 10 for US$27.45 each and save 3%
- Buy 30 for US$26.66 each and save 5%
- Buy 50 for US$25.96 each and save 8%
- Buy 100 for US$25.22 each and save 11%
- Buy 500 or more Quote Request
Shipping
Payment
Tax Info
Warranty
Return Policy
Continulty Supply
-
This Item:
Raspberry Pi 5 inch 1024x600 IPS TFT LCD Display w/HDMI Driver Board
US$28.19
-
AC100-240V To DC 5V 2A Power Supply Adapter for TFT Driving Board
US$3.11
-
Total price
Description
Stunning Visuals with True-to-Life Colors
The ER-TFT050B1-1-3938 is a 5-inch IPS color TFT display that brings content to life with a sharp 1024×600 pixel resolution and an exceptionally fine 0.105×0.108 mm dot pitch for outstanding image clarity. Its remarkable 1200:1 contrast ratio delivers deep, rich blacks and vivid, saturated colors, while full 16.7M color support ensures every gradient and hue is reproduced with stunning accuracy. Whether displaying detailed graphical interfaces, high-resolution images, or smooth video content, this panel offers the color fidelity and pixel definition that professional applications demand.
Ultra-High Brightness with Super Wide Viewing Angle
Engineered for visibility in any environment, the display boasts a powerful 800 cd/m² brightness that keeps screens clearly readable even under bright ambient light. Advanced IPS technology provides a full 80° viewing angle in all four directions—left, right, up, and down—guaranteeing zero color shift or contrast degradation regardless of viewing position. With a rapid 15 ms typical response time, fast-moving visuals remain crisp and ghost-free, making it an ideal solution for industrial HMIs, portable instrumentation, medical monitors, and embedded systems where optical performance cannot be compromised.
Plug-and-Play HDMI Connectivity for Leading Development Boards
This variant features a compact HDMI driver board that delivers true plug-and-play compatibility with mainstream single-board computers and mini-PCs. It connects seamlessly to Raspberry Pi, BeagleBone Black, LattePanda, UDOO, Odroid, and virtually any platform with an HDMI output—no complex initialization code, SPI timing, or framebuffer configuration required. Simply power, connect, and display: your OS desktop, video stream, or application UI appears instantly.
Flexible Touch Options and Streamlined User Interaction
Interactivity is fully customizable to suit your end product. Choose an optional 4-wire resistive touch panel with dedicated USB driver board and cable for precise stylus or gloved-finger input, or upgrade to an optional capacitive touch panel with USB controller board and cable for smooth, responsive multi-touch gestures. For hands-free or kiosk-style operation, an optional remote control adds effortless menu navigation and command input. Combined with a wide -20°C to +70°C operating temperature range, these features make the ER-TFT050B1-1-3938 a robust, ready-to-deploy display solution for industrial automation, medical equipment, handheld devices, and next-generation embedded projects.
When lose signal,the screen is blue or black that is available in the menu setting.There is no snowy screen or white noise in setting menu.
What's included in the package ?
| Number | Standard Accessory Name | Qty |
|---|---|---|
| 1 | 5 inch IPS TFT LCD 1024x600 Pixels Display | 1 |
| 2 | Small HDMI Driver Board | 1 |
| 3 | Keyboard Cable with Terminal | 1 |
| 4 | 50 to 40 Pins Adaptor Board | 1 |
| 5 | Power Cable with Terminal | 1 |
Datasheet
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
 |
ER-TFT050B1-1-3938 Datasheet | English | Sep-03-2026 | 1.2M |
Datasheet for Capacitive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
ER-TPC050-5-USB Outline Drawing | English |
May-30-2018
|
294K
|
Datasheet for Resistive Touch Panel and USB Controller Board
| Format | Documents Name | Language | Update Date | Size |
|---|---|---|---|---|
|
English |
Mar-02-2013
|
180K | |
|
English |
Jun-19-2013
|
190K | |
 |
English |
Jul-08-2013
|
56M |
| Gross Weight (kg) | 0.2050 |
|---|---|
| Manufacturer | EastRising |
| Continuity Supply | We promise the long term continuity supply for this product no less than 10 years since 2026. |
| Part Number | ER-TFT050B1-1-3938 |
| Display Format | 1024x600 Pixels |
| Interface | HDMI |
| IC or Equivalent | RTD2660H |
| Appearance | RGB |
| Diagonal Size | 5.0“ |
| Connection | Plug-in FPC |
| Outline Dimension | 120.70(W)x75.80(H)mm |
| Visual Area | 110.70x67.40mm |
| Active Area | 108.03(W)x64.80(H)mm |
| Dot (Pixel) Pitch | 0.105(W)x0.108(H)mm |
| IC Package | COG |
| Display Type | TFT-LCD Color |
| Touch Panel Optional | Yes |
| Sunlight Readable | No |
| Contrast Ratio(Typ) | 1200:1 |
| Colors | 65K/262K/16.7M |
| Viewing Direction | IPS |
| Viewing Angle Range | Left:80.0 , Right:80.0 , Up:80.0 , Down:80.0 degree |
| Brightness(Typ) | 800cd/m2 |
| Backlight Color | White Color |
| Backlight Current (Typ) | 40mA |
| Power Supply(Typ) | 5V |
| Supply Current for LCM(Max) | 220mA |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
